Fly Sierra 3 Frame

After another amazing year for Sergio Layos, Fly have only made a few small changes to make his signature frame even better. Sergio has decided to make the move back to a 75° head tube angle, The frame features internal and external gussets, multi-butted and tapered tubing, an Investment Cast seat post clamp with the Horizontal Cut System, removable EBS style brake mounts and Investment Cast Dropouts with integrated chain tensioners!

###section###

Product Specs
  1. MATERIAL: 4130 Chromoly
  2. HEAD TUBE ANGLE: 75°
  3. SEAT TUBE ANGLE: 71°
  4. CHAIN STAY LENGTH: 13.6"
  5. BB HEIGHT: 11.5"
  6. WHEEL SIZE: 20"
  7. STANDOVER HEIGHT: 8.75"
  8. DROPOUT SIZE: 14mm
  9. HEADSET TYPE: Integrated
  10. BB TYPE: Mid
  11. BRAKE MOUNTS: Removable
  12. GYRO TABS: Drilled
  13. WEIGHT: 5lbs

###section###

Product Highlights
  • Neutral Geometry for responsiveness and stability
  • Great all round frame for all types of riding
  • High-quality Chromoly construction
  • Gusseted tubing for added strength
  • Built in chain tensioners

###shogun-image-section###

Select Colour
Select Size
From $148.04

Original: $422.96

-65%
Fly Sierra 3 Frame—

$422.96

$148.04

Product Information

Shipping & Returns

Description

After another amazing year for Sergio Layos, Fly have only made a few small changes to make his signature frame even better. Sergio has decided to make the move back to a 75° head tube angle, The frame features internal and external gussets, multi-butted and tapered tubing, an Investment Cast seat post clamp with the Horizontal Cut System, removable EBS style brake mounts and Investment Cast Dropouts with integrated chain tensioners!

###section###

Product Specs
  1. MATERIAL: 4130 Chromoly
  2. HEAD TUBE ANGLE: 75°
  3. SEAT TUBE ANGLE: 71°
  4. CHAIN STAY LENGTH: 13.6"
  5. BB HEIGHT: 11.5"
  6. WHEEL SIZE: 20"
  7. STANDOVER HEIGHT: 8.75"
  8. DROPOUT SIZE: 14mm
  9. HEADSET TYPE: Integrated
  10. BB TYPE: Mid
  11. BRAKE MOUNTS: Removable
  12. GYRO TABS: Drilled
  13. WEIGHT: 5lbs

###section###

Product Highlights
  • Neutral Geometry for responsiveness and stability
  • Great all round frame for all types of riding
  • High-quality Chromoly construction
  • Gusseted tubing for added strength
  • Built in chain tensioners

###shogun-image-section###
